TP-LINK Video recorder 8 Csatornás Wireless, VIGI NVR1108H-W

• Details
• Data
• Reviews

Details

Video and Audio
IP Video Input	8-Channel
Incoming Bandwidth	80 Mbps
Outgoing Bandwidth	60 Mbps
HDMI Output Resolution	1 Channel, Resolution: 3840 ×2160/30Hz, 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
VGA Output Resolution	1 Channel, Resolution: 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Video Output Mode	HDMI/VGA Simultaneous Output
Multi-View Display	1/4/6/8

DESCODIFICACIÓN
Audio Compression	G.711A/G.711U/G.726
Video Compression	H.265+/H.265/ H.264+/H.264
Record Resolution	8 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Reproducción síncrona	8-Channel†
Capacidad	2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP

Record Management
Record Mode	• Manual Recording • Scheduling Recording • Motion Detection Recording
Playback Mode	• Instant Playback • Regular Playback • Tag Playback • Event Playback
Backup Mode	• Regular Backup • Video Clip Backup
Playback Function	• Play • Pause • Stop • Fast Forward • Fast Backward • Play By Frame • Full Screen • Video Clip • Export Clip • Digital Zoom • Lock Recording • Audio On/Off

Red
Protocolo	UPnP (Plug and Play), NTP (Network Timing), SMTP, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
Mobile Phone Access	Android, iOS
Web Browser	Chrome (57+), Firefox (52+), Edge (91+)
Interoperability	ONVIF, CGI

Inalámbricos
Estándares	IEEE 802.11b/g/n
Canales Wi-Fi	• UN: 1-13 • US: 1-11
Wireless Name	• SSID Configuration • Radio
Network Switch	Yes
Frecuencia	2.4 GHz
Auto Wireless Channel	N/A
Wireless Statistics	N/A
Throughput Monitoring	N/A
Radio Bandwidth	• Auto: Yes • 20M: Yes • 40M: Yes
Wireless Rate	300Mbps(802.11n), 2 × 2 MIMO
Wireless Security	WPA-PSK/WPA2-PSK

External Interface
Network Interface	• 1× RJ-45 10/100 Mbps Self-Adaptive WAN/LAN Ethernet Interface • 1× RJ-45 10/100 Mbps Self-Adaptive LAN Ethernet Interface
USB Interface	2× USB 2.0
Audio Interface	1-ch RCA Input; 1-ch RCA Output
Alarm In/Out	N/A
Serial Interface	N/A
Power	1× DC Jack
Reset Button	1
Speaker	1; Real-time Audio Output without Needing Peripherals.
eSATA	N/A
HDMI	1
VGA	1

HDD
SATA	1 SATA Interface
Capacidad	Up to 16 TB Capacity for Each HDD**

Alarm
General Alarm	• Motion Detection • Video Tampering • Scene Change Detection • Line-Crossing Detection • Intrusion Detection • Region Entering Detection • Region Exiting Detection • Loitering Detection • Object Abandoned/Removal Detection • Vehicle Detection • Human Detection • Abnormal Sound Detection • Smart Frame
Anomaly Alarm	• Video Loss • Offline and IP Conflict • Disk Exception • Login Exception
Alarm Linkage	• Recording • White Light Alarm • Log • Audible Alarm

GENERAL
Storage Temperature	-40–70 °C
Storage Humidity	10%~90% RH Non-Condensing
Contenido del Paquete	• VIGI Network Video Recorder • Power Adapter • HDD Screws • Mouse • Quick Installation Guide
Working Temperature	• NVR: -10–55 °C • Power Adapter: 0–40 °C
Working Humidity	10%~90% RH Non-Condensing
Dimensiones	Excluding Antennas: 200.3 × 200.3 × 43 mm (7.9 × 7.9 × 1.7 in)
Fuente de Alimentación Externa	DC 12V/2A
Peso neto	0.5 kg
Peso bruto	1.0 kg
Consumo energético	• 5.7 W (Without Disk) • 16.3 W (Without Disk)
Antenna	• Quantity: 2 • Type: 2.4GHz Welded Non-detachable Antenna • Gain: 5.3dBi • Radio Frequency Transmit Power: 16dBm • Length: 198.8 mm for Long Side and 189 mm for Short Side
Certificaciones	BSMI, CE, HDMI, JRF, KC, NCC, NTRA, VCCI

Data

Listaár:

116 002 HUF

Gyártó:

TP-LINK

Gyártói cikkszám:

VIGI NVR1108H-W

EAN:

4895252504934

Garancia:

48 hónap

EAN:

4895252504934

Garancia (hónap):

48

Termék gyártója:

TP-LINK

Gyártó:

TP-LINK

KSH szám:

8525890000

Weight:

1,06 kg/db
